| PRODUCT NO. TIP NO. | TIP NO | A | B | C | WEIGHT IN GRAMS |
| T-5 | T-5 | 140 | 75 | 3.0 | 22 |
| T-5L | T-5 | 215 | 150 | 3.0 | 28 |
| T-6 | T-6 | 150 | 75 | 3.0 | 22 |
| T-6L | T-6 | 225 | 150 | 3.0 | 28 |
| T-8 | T-8 | 150 | 75 | 3.5 | 25 |
| T-8L | T-8 | 225 | 150 | 3.5 | 35 |
| T-10 | T-10 | 150 | 75 | 3.5 | 25 |
| T-10L | T-10 | 225 | 150 | 3.5 | 35 |
| T-15 | T-15 | 161 | 75 | 5.0 | 50 |
| T-15L | T-15 | 225 | 150 | 5.0 | 60 |
| T-20 | T-20 | 225 | 150 | 5.0 | 55 |
| T-20L | T-20 | 286 | 100 | 5.0 | 65 |
| T-25 | T-25 | 198 | 200 | 6.0 | 90 |
| T-25L | T-25 | 298 | 200 | 6.0 | 105 |
| T-30 | T-30 | 198 | 100 | 6.0 | 90 |
| T-30L | T-30 | 298 | 200 | 6.0 | 105 |
| T-40 | T-40 | 230 | 125 | 8.0 | 120 |
| T-40L | T-40 | 305 | 200 | 8.0 | 150 |
| The blade is made from high grade Silico – Manganese steel. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Scientifically heat treated blade gives maximum strength & wear resistance. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The tip is precision – ground to ensures firm grip in the screw slot. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The blade tip is magnetized to lift small screws from confined spaces or to hold the screw in position. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bright & smooth Nickel Chrome plating finish effectively protects blade against corrosion. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The handle is made from high grade special Plastic to enable high strength and durability. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The handle is precisely designed to give comfortable grip even at higher torque. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The specially designed steel cap and blade assembly facilitates the striking screw driver for hammering without damaging the handle. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| In electrician pattern, PVC insulation on blade protects from electric shock & withstands for high voltage insulation test at 2000 V DC. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Available
in different patterns viz. Engineer’s, Electrician’s, Stubby, Phillips,
Poker, Striking, Torx, Hexagon etc., Two-in-One (Black Tip) – Regular &
Stubby. Minimum Torque Value in Kg.m: Flat Tip
Philips Tip
TAPARIA Screwdrivers are generally conform to I.S.844-1979 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
